| Datasheet |  AN-2813 datasheet |
|---|
| Product Photos | AN-2813AN-2813 |
|---|
| Product Training Modules | Avoiding the Top 5 Pitfalls of NEMA EnclosuresModified Enclosures |
|---|
| Video File | Bud's Custom CapabilitiesCustom BUD Box Enclosures – Another Geek Moment |
|---|
| Catalog Drawings | AN-28, CN-67 Series |
|---|
| Featured Product | Customize Your EnclosureAN-Series Waterproof Enclosures |
|---|
| 2D Drawing | AN-1313(-G), AN-2813(-B).dxf |
|---|
| Standard Package | 1 |
|---|
| Category | Boxes, Enclosures, Racks |
|---|
| Family | Boxes |
|---|
| Series | AN |
|---|
| Container Type | Box with Mounting Flange |
|---|
| Size / Dimension | 4.900" L x 3.140" W (124.46mm x 79.76mm) |
|---|
| Height | 1.590" (40.39mm) |
|---|
| Area (L x W) | 15.4" (99cm) |
|---|
| Design | Cover Included |
|---|
| Material | Metal, Aluminum |
|---|
| Color | Natural |
|---|
| Thickness | 0.120" (3.05mm) |
|---|
| Features | PCB Supports, Watertight |
|---|
| Ratings | IP65, IP66, NEMA 1,2,4,4X,12,13, UL-508 |
|---|
| Material Flammability Rating | - |
|---|
| Shipping Info | Shipped from Digi-Key |
|---|
| Weight | 1 lb (453.59g) |
|---|
| Associated Product | 377-1606-ND - KIT WALL MOUNTING BRACKET NAT 377-1607-ND - KIT WALL MOUNTING BRACKET BLACK 377-1608-ND - KIT WALL MOUNTING BRACKET GRAY ANX-91313-ND - PANEL ALUM 4.48X2.72X0.06" |
|---|
| Alternate Color | 377-1453-ND - BOX ALUM BLACK 4.9"L X 3.14"W |
|---|
| Other Names | 377-1452 AN 2813 AN2813 |
|---|
