Technical Specifications of M3DGK-2020K
| Datasheet |  M3DGK-2020K datasheet |
|---|
| Product Photos | M3DGK-20 T |
|---|
| Product Training Modules | Cable Matters |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Card Edge |
|---|
| Number of Positions | 20 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 1.67' (508.10mm) |
|---|
| Features | Polarizing Key, Strain Relief (Socket); Flange (Card Edge) |
|---|
| Color | Multiple, Twisted Pair (Flat) |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Assembly Component | (1) MKC20K-ND - SOCK CONN 20 CONT OPEN W/POL GLD (1) MSSR20-ND - STRAIN RELIEF 20 CONT SOCK CONN (1) MCS20K-ND - CARD EDGE CONN 20POS W/FLANGE (1) MC20F-100-ND - CBL RIBN 20COND TWIST-PAIR 100' |
|---|
| Alternate Length | M3DGK-2040K-ND - IDC CABLE - MKR20K/MC20F/MCS20K M3DGK-2060K-ND - IDC CABLE - MKR20K/MC20F/MCS20K |
|---|
We can supply 3M part# M3DGK-2020K. Use the request quote form to request M3DGK-2020K pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M3DGK-2020K. The price and lead time for M3DGK-2020K depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M3DGK-2020K. We look forward to doing business with you.
