Technical Specifications of C8PPG-1618M
| Datasheet |  C8PPG-1618M datasheet |
|---|
| Product Photos | CxPPG-16 MPart Number Breakdown CW |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | DIP to DIP, Reversed |
|---|
| Number of Positions | 16 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 1.50' (457.20mm) |
|---|
| Features | - |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | Socket (0.3"), Board In |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 10μin (0.25μm) |
|---|
| Online Catalog | DIP to DIP, Reversed Cable Assemblies |
|---|
| Assembly Component | (2) CDP16G-ND - CONNECTOR DIP 16 PIN GOLD IDC (1) AE16M-300-ND - CBL RIBN 16COND 0.050 MULTI 300' |
|---|
| Alternate Color | C8PPG-1618G-ND - DIP CABLE - CDP16G/AE16G/CDP16G |
|---|
| Alternate Length | C8PPG-1606M-ND - DIP CABLE - CDP16G/AE16M/CDP16G C8PPG-1636M-ND - DIP CABLE - CDP16G/AE16M/CDP16G |
|---|
| Other Names | R118-18 |
|---|
We can supply CW Industries part# C8PPG-1618M. Use the request quote form to request C8PPG-1618M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C8PPG-1618M. The price and lead time for C8PPG-1618M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C8PPG-1618M. We look forward to doing business with you.
