Technical Specifications of H2MXH-2036G
| Datasheet |  H2MXH-2036G datasheet |
|---|
| Product Photos | H2MXH-20 GPart Number Breakdown Assmann |
|---|
| Featured Product | Assmann - IDC Connectors and Cables |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | DIP to Cable |
|---|
| Number of Positions | 20 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | - |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | Socket (0.1"), Board In |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Assembly Component | (1) AE20G-300-ND - CBL RIBN 20COND 0.050 GRAY 300' (1) HDM20H-ND - CONN DIP 20POS .1" X .1" GOLD |
|---|
| Alternate Color | H2MXH-2036M-ND - DIP CABLE - HDM20H/AE20M/X |
|---|
| Alternate Length | H2MXH-2006G-ND - DIP CABLE - HDM20H/AE20G/X H2MXH-2018G-ND - DIP CABLE - HDM20H/AE20G/X |
|---|
We can supply Assmann WSW Components part# H2MXH-2036G. Use the request quote form to request H2MXH-2036G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number H2MXH-2036G. The price and lead time for H2MXH-2036G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# H2MXH-2036G. We look forward to doing business with you.
