Technical Specifications of C3CES-2018G
| Datasheet |  C3CES-2018G datasheet |
|---|
| Product Photos | C3CEx-20 G |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Card Edge |
|---|
| Number of Positions | 20 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 1.50' (457.20mm) |
|---|
| Features | Polarizing Key |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | Board In |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Tin |
|---|
| Contact Finish Thickness | 100μin (2.54μm) |
|---|
| Online Catalog | Socket to Card Edge Cable Assemblies |
|---|
| Assembly Component | (1) CKC20S-ND - CONN SOCKET 20PIN TIN W/KEY (1) AE20G-300-ND - CBL RIBN 20COND 0.050 GRAY 300' (1) CCE20S-ND - CONN CARDEDGE 20PIN TIN W/ORS |
|---|
| Alternate Color | C3CES-2018M-ND - IDC CABLE - CKC20S/AE20M/CCE20S |
|---|
| Alternate Length | C3CES-2006G-ND - IDC CABLE - CKC20S/AE20G/CCE20S C3CES-2036G-ND - IDC CABLE - CKC20S/AE20G/CCE20S |
|---|
We can supply CW Industries part# C3CES-2018G. Use the request quote form to request C3CES-2018G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C3CES-2018G. The price and lead time for C3CES-2018G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C3CES-2018G. We look forward to doing business with you.
