Technical Specifications of EEV-TG1K220P
| Product Photos | TG SERIES |
|---|
| Catalog Drawings | TG Series Bottom_GTG Series Side_G |
|---|
| PCN Obsolescence/ EOL | ECE, EEV Series 30/Sept/2010 |
|---|
| Standard Package | 500 |
|---|
| Category | Capacitors |
|---|
| Family | Aluminum Capacitors |
|---|
| Series | TG |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 22μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage Rating | 80V |
|---|
| ESR (Equivalent Series Resistance) | 1 Ohm @ 100kHz |
|---|
| Lifetime @ Temp. | 2000 Hrs @ 125°C |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Polarization | Polar |
|---|
| Applications | Automotive |
|---|
| Ripple Current | 58.5mA @ 120Hz |
|---|
| Impedance | - |
|---|
| Lead Spacing | - |
|---|
| Size / Dimension | 0.394" Dia (10.00mm) |
|---|
| Height - Seated (Max) | 0.402" (10.20mm) |
|---|
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Radial, Can - SMD |
|---|
| Other Names | EEVTG1K220P PCE3671TR |
|---|
We can supply Panasonic Electronic Components part# EEV-TG1K220P. Use the request quote form to request EEV-TG1K220P pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number EEV-TG1K220P. The price and lead time for EEV-TG1K220P depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# EEV-TG1K220P. We look forward to doing business with you.
