| Datasheet |  CGA5L3X5R1H155M160AB datasheet |
|---|
| Product Photos | CGA Series 1206 (3216 Metric) 1.8 |
|---|
| Product Training Modules | CGA Series for Automotive ApplicationsSEAT, CCV, and TVCL Design ToolsGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | CGA Series, RoHS Cert of Compliance |
|---|
| Featured Product | CGA Series MLCC Capacitors |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 2,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | CGA |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 1.5μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage - Rated | 50V |
|---|
| Temperature Coefficient | X5R |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 85°C |
|---|
| Applications | Automotive |
|---|
| Ratings | AEC-Q200 |
|---|
| Package / Case | 1206 (3216 Metric) |
|---|
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.60mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.071" (1.80mm) |
|---|
| Lead Spacing | - |
|---|
| Features | - |
|---|
| Lead Style | - |
|---|
| Online Catalog | CGA Series, Automotive General, Mid and High Voltage |
|---|
| Other Names | 445-12880-2 CGA5L3X5R1H155MT0Y0N |
|---|
