| Datasheet |  C3225X8R2A684K250AB datasheet |
|---|
| Product Photos | C Series 1210(3225 Metric) 28 |
|---|
| Product Training Modules | SEAT, CCV, and TVCL Design ToolsC Series High Temp Capacitor FamilyGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Featured Product | C-Series Mid Voltage MLCCs |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | C |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 0.68μF |
|---|
| Tolerance | ±10% |
|---|
| Voltage - Rated | 100V |
|---|
| Temperature Coefficient | X8R |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 150°C |
|---|
| Applications | General Purpose |
|---|
| Ratings | - |
|---|
| Package / Case | 1210 (3225 Metric) |
|---|
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.110" (2.80mm) |
|---|
| Lead Spacing | - |
|---|
| Features | High Temperature |
|---|
| Lead Style | - |
|---|
| Online Catalog | C Series, High Temperature |
|---|
| Other Names | 445-14953-2 C3225X8R2A684KT000N |
|---|
