| Datasheet |  CKG45NX7S1C476M500JJ datasheet |
|---|
| Product Photos | CKG45N, CKG57N Series |
|---|
| Product Training Modules | CKG Series Capacitor Family MEGACAP TypeSEAT, CCV, and TVCL Design ToolsGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Featured Product | CKG Series Multilayer Ceramic Chip Capacitors |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | CKG |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 47μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage - Rated | 16V |
|---|
| Temperature Coefficient | X7S |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Applications | Automotive, SMPS Filtering, Bypass, Decoupling |
|---|
| Ratings | AEC-Q200 |
|---|
| Package / Case | Stacked SMD, 2 J-Lead |
|---|
| Size / Dimension | 0.197" L x 0.138" W (5.00mm x 3.50mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.217" (5.50mm) |
|---|
| Lead Spacing | - |
|---|
| Features | Low ESL (Stacked) |
|---|
| Lead Style | J-Lead |
|---|
| Online Catalog | CKG Series, MEGACAP |
|---|
| Other Names | 445-10416-2 CKG45NX7S1C476MT0Y9W |
|---|
