Technical Specifications of C0603X5R1E471K030BA
| Datasheet |  C0603X5R1E471K030BA datasheet |
|---|
| Product Photos | 0201 PKG |
|---|
| Product Training Modules | C Series General ApplicationsSEAT, CCV, and TVCL Design ToolsGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 15,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | C |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 470pF |
|---|
| Tolerance | ±10% |
|---|
| Voltage - Rated | 25V |
|---|
| Temperature Coefficient | X5R |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 85°C |
|---|
| Applications | General Purpose |
|---|
| Ratings | - |
|---|
| Package / Case | 0201 (0603 Metric) |
|---|
| Size / Dimension | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.013" (0.33mm) |
|---|
| Lead Spacing | - |
|---|
| Features | Low ESL |
|---|
| Lead Style | - |
|---|
| Online Catalog | C Series, General Purpose |
|---|
| Other Names | 445-4691-2 C0603X5R1E471K C0603X5R1E471KT00NN |
|---|
We can supply TDK Corporation part# C0603X5R1E471K030BA. Use the request quote form to request C0603X5R1E471K030BA pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C0603X5R1E471K030BA. The price and lead time for C0603X5R1E471K030BA depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C0603X5R1E471K030BA. We look forward to doing business with you.
