Technical Specifications of C5750X7S2A685M200KB
| Datasheet |  C5750X7S2A685M200KB datasheet |
|---|
| Product Photos | C Series 2220(5750 Metric) 25 |
|---|
| Product Training Modules | SEAT, CCV, and TVCL Design ToolsC Series Mid Voltage Capacitors FamilyGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Featured Product | Mid Voltage X7S 100 V MLCCsC-Series Mid Voltage MLCCs |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 500 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | C |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 6.8μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage - Rated | 100V |
|---|
| Temperature Coefficient | X7S |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Applications | General Purpose |
|---|
| Ratings | - |
|---|
| Package / Case | 2220 (5750 Metric) |
|---|
| Size / Dimension | 0.224" L x 0.197" W (5.70mm x 5.00mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.087" (2.20mm) |
|---|
| Lead Spacing | - |
|---|
| Features | - |
|---|
| Lead Style | - |
|---|
| Online Catalog | C Series, Mid Voltage |
|---|
| Other Names | 445-13410-2 C5750X7S2A685MT000N |
|---|
We can supply TDK Corporation part# C5750X7S2A685M200KB. Use the request quote form to request C5750X7S2A685M200KB pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C5750X7S2A685M200KB. The price and lead time for C5750X7S2A685M200KB depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C5750X7S2A685M200KB. We look forward to doing business with you.
