Technical Specifications of CWR09HC106KB
| Datasheet |  CWR09HC106KB datasheet |
|---|
| Product Photos | CWR09-Series-2214-pkg |
|---|
| Product Training Modules | Capacitor Basics- Typical Uses for CapacitorsMilitary Product Overview |
|---|
| Featured Product | CWR MIL-PRF-55365 Tantalum Surface Mount Series |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1,000 |
|---|
| Category | Capacitors |
|---|
| Family | Tantalum Capacitors |
|---|
| Series | Military, MIL-PRF-55365/4, CWR09 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 10μF |
|---|
| Tolerance | ±10% |
|---|
| Voltage - Rated | 15V |
|---|
| ESR (Equivalent Series Resistance) | 2.5 Ohm |
|---|
| Type | Molded |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2214 (5634 Metric) |
|---|
| Size / Dimension | 0.220" L x 0.135" W (5.59mm x 3.43mm) |
|---|
| Height - Seated (Max) | 0.085" (2.16mm) |
|---|
| Lead Spacing | - |
|---|
| Manufacturer Size Code | - |
|---|
| Features | Military |
|---|
| Failure Rate | B (0.1%) |
|---|
| Lifetime @ Temp. | - |
|---|
| Online Catalog | Military, MIL-PRF-55365 4, CWR09, T409 Series |
|---|
| Other Names | 1001-2311-2 CWR09HC106KB7370 T409F106K015BC |
|---|
We can supply Kemet [MIL] part# CWR09HC106KB. Use the request quote form to request CWR09HC106KB pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CWR09HC106KB. The price and lead time for CWR09HC106KB depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CWR09HC106KB. We look forward to doing business with you.
