Technical Specifications of SS-5-5A-AP
| Datasheet |  SS-5-5A-AP datasheet |
|---|
| Product Photos | SS-5, SS-5H Series; ending AP |
|---|
| PCN Design/Specification | SS-5(H) Ammo Pack Paper Thickness 30/Aug/2011S -8yyy,HTC-yy,PC,SR-5,SS-5 Series 01/May/2014 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | Fuses |
|---|
| Series | SS-5 |
|---|
| Packaging | Tape & Box (TB) |
|---|
| Fuse Type | Board Mount (Cartridge Style Excluded) |
|---|
| Current Rating | 5A |
|---|
| Voltage Rating - AC | 250V |
|---|
| Voltage Rating - DC | - |
|---|
| Response Time | Slow |
|---|
| Package / Case | Radial, Box |
|---|
| Mounting Type | Through Hole |
|---|
| Breaking Capacity @ Rated Voltage | 50A |
|---|
| Melting I2t | 120 |
|---|
| Approvals | CQC, cULus, EK-MARK, SEMKO, VDE |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Color | - |
|---|
| Size / Dimension | 0.335" L x 0.169" W x 0.329" H (8.50mm x 4.30mm x 8.35mm) |
|---|
| DC Cold Resistance | 0.00735 Ohm |
|---|
| Online Catalog | SS-5 Series |
|---|
| Other Names | 283-3217-3 SS-5-5A-AP-ND SS55AAP |
|---|
We can supply Eaton part# SS-5-5A-AP. Use the request quote form to request SS-5-5A-AP pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SS-5-5A-AP. The price and lead time for SS-5-5A-AP depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SS-5-5A-AP. We look forward to doing business with you.
