Technical Specifications of 0154003.DRL
| Datasheet |  0154003.DRL datasheet |
|---|
| Product Photos | Omni-Blok-Series-Black |
|---|
| Product Training Modules | Fuseology - Introduction to Fuses |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1,500 |
|---|
| Category | Circuit Protection |
|---|
| Family | Fuses |
|---|
| Series | OMNI-BLOK? 154L |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Fuse Type | Board Mount (Cartridge Style Excluded) |
|---|
| Current Rating | 3A |
|---|
| Voltage Rating - AC | 125V |
|---|
| Voltage Rating - DC | 125V |
|---|
| Response Time | Fast |
|---|
| Package / Case | 2-SMD, Square End Block with Holder |
|---|
| Mounting Type | Holder/Surface Mount |
|---|
| Breaking Capacity @ Rated Voltage | 50A |
|---|
| Melting I2t | 1.65 |
|---|
| Approvals | PSE, UL |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Color | - |
|---|
| Size / Dimension | 0.383" L x 0.198" W x 0.150" H (9.73mm x 5.03mm x 3.81mm) |
|---|
| DC Cold Resistance | 0.0227 Ohm |
|---|
| Online Catalog | OMNI-BLOK? 154 Series |
|---|
| Associated Product | F2583TR-ND - FUSE BRD MNT 3A 125VAC/VDC 2SMD F2583CT-ND - FUSE BRD MNT 3A 125VAC/VDC 2SMD F2583DKR-ND - FUSE BRD MNT 3A 125VAC/VDC 2SMD F7131TR-ND - FUSE BRD MNT 3A 125VAC/VDC 2SMD 0451003.NR-ND - FUSE BRD MNT 3A 125VAC/VDC 2SMD F1147TR-ND - FUSE BRD MNT 3A 125VAC/VDC 2SMD F1147CT-ND - FUSE BRD MNT 3A 125VAC/VDC 2SMD F1147DKR-ND - FUSE BRD MNT 3A 125VAC/VDC 2SMD |
|---|
| Alternate Color | F1226TR-ND - FUSE BOARD MNT 3A 125VAC/VDC SMD |
|---|
| Other Names | 0154003.DRL-ND 154003.DRL F6006TR |
|---|
We can supply Littelfuse Inc. part# 0154003.DRL. Use the request quote form to request 0154003.DRL pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 0154003.DRL. The price and lead time for 0154003.DRL depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 0154003.DRL. We look forward to doing business with you.
