Technical Specifications of S505-10-R
| Datasheet |  S505-10-R datasheet |
|---|
| Product Photos | S505 cylindrical |
|---|
| PCN Design/Specification | S505 Series Select Ratings 5/Feb/2009 |
|---|
| Standard Package | 5 |
|---|
| Category | Circuit Protection |
|---|
| Family | Fuses |
|---|
| Series | S505 |
|---|
| Packaging | Bulk |
|---|
| Fuse Type | Cartridge, Ceramic |
|---|
| Current Rating | 10A |
|---|
| Voltage Rating - AC | 250V |
|---|
| Voltage Rating - DC | - |
|---|
| Response Time | Slow |
|---|
| Package / Case | 5mm x 20mm |
|---|
| Mounting Type | Holder |
|---|
| Breaking Capacity @ Rated Voltage | 1.5kA |
|---|
| Melting I2t | 397 |
|---|
| Approvals | BSI, CQC, CSA, cULus, IMQ, KC, PSE/JET, SEMKO, VDE |
|---|
| Operating Temperature | - |
|---|
| Color | - |
|---|
| Size / Dimension | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) |
|---|
| DC Cold Resistance | 0.0061 Ohm |
|---|
We can supply Eaton part# S505-10-R. Use the request quote form to request S505-10-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number S505-10-R. The price and lead time for S505-10-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# S505-10-R. We look forward to doing business with you.
