Technical Specifications of BK/MDL-3/4-R
| Datasheet |  BK/MDL-3/4-R datasheet |
|---|
| Product Photos | MDL Cylindrical 3AG |
|---|
| Product Training Modules | Selecting Fuses - Simple Procedures for Proper Overcurrent Protection of DC-DC Converters |
|---|
| Catalog Drawings | AGC-R, MDL-R Series |
|---|
| Standard Package | 100 |
|---|
| Category | Circuit Protection |
|---|
| Family | Fuses |
|---|
| Series | MDL |
|---|
| Packaging | Bulk |
|---|
| Fuse Type | Cartridge, Glass |
|---|
| Current Rating | 750mA |
|---|
| Voltage Rating - AC | 250V |
|---|
| Voltage Rating - DC | - |
|---|
| Response Time | Slow |
|---|
| Package / Case | 3AB, 3AG, 1/4" x 1-1/4" |
|---|
| Mounting Type | Holder |
|---|
| Breaking Capacity @ Rated Voltage | 35A |
|---|
| Melting I2t | 4.343 |
|---|
| Approvals | CE, CSA, UL |
|---|
| Operating Temperature | - |
|---|
| Color | - |
|---|
| Size / Dimension | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) |
|---|
| DC Cold Resistance | 0.397 Ohm |
|---|
| Online Catalog | MDL Series |
|---|
| Associated Product | 283-2601-ND - FUSE CLIP CARTRIDGE PCB 283-2711-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2714-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2851-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2850-ND - FUSE HLDR CART 250V 30A PNL MNT 283-2849-ND - FUSE HLDR CART 250V 15A PNL MNT 283-2847-ND - FUSE HLDR CART 250V 20A IN LINE 283-2598-ND - FUSE CLIP CARTRIDGE PCB 283-2599-ND - FUSE CLIP CARTRIDGE PCB 283-2826-ND - FUSE CLIP CARTRIDGE PCB 283-2342-ND - FUSE CLIP CARTRIDGE PCB 283-2709-ND - FUSE HLDR CARTRIDGE 250V 16A PCB 283-2715-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2717-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2718-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2852-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2864-ND - FUSE CLIP CARTRIDGE PCB 283-2719-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2855-ND - FUSE HLDR CART 250V 20A PNL MNT 283-2602-ND - FUSE CLIP CARTRIDGE PCB 283-2831-ND - FUSE CLIP CARTRIDGE PCB 283-2337-ND - FUSE CLIP CARTRIDGE CHASSIS MNT 283-2825-ND - FUSE CLIP CARTRIDGE PCB |
|---|
| Other Names | 283-2747 BK-MDL-3-4-R BK/MDL-3/4R BK/MDL3/4R |
|---|
We can supply Eaton part# BK/MDL-3/4-R. Use the request quote form to request BK/MDL-3/4-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number BK/MDL-3/4-R. The price and lead time for BK/MDL-3/4-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# BK/MDL-3/4-R. We look forward to doing business with you.
