Technical Specifications of RCLAMP0504S.TCT
| Datasheet |  RCLAMP0504S.TCT datasheet |
|---|
| Product Photos | SOT-23-6 |
|---|
| PCN Assembly/Origin | Qualifcation of Material 09/May/2014 |
|---|
| Standard Package | 3,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | RailClamp? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Steering (Rail to Rail) |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 4 |
|---|
| Voltage - Reverse Standoff (Typ) | 5V |
|---|
| Voltage - Breakdown (Min) | 6V |
|---|
| Voltage - Clamping (Max) @ Ipp | 25V |
|---|
| Current - Peak Pulse (10/1000μs) | 6A (8/20μs) |
|---|
| Power - Peak Pulse | 150W |
|---|
| Power Line Protection | Yes |
|---|
| Applications | Ethernet, USB OTG |
|---|
| Capacitance @ Frequency | 3pF @ 1MHz |
|---|
| Operating Temperature | -55°C ~ 125°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SOT-23-6 |
|---|
| Supplier Device Package | SOT-23-6 |
|---|
| Online Catalog | RailClamp? |
|---|
| Other Names | RCLAMP0504STCT RCLAMP0504STR |
|---|
We can supply Semtech Corporation part# RCLAMP0504S.TCT. Use the request quote form to request RCLAMP0504S.TCT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number RCLAMP0504S.TCT. The price and lead time for RCLAMP0504S.TCT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# RCLAMP0504S.TCT. We look forward to doing business with you.
