Technical Specifications of SP0505BAJTG
| Datasheet |  SP0505BAJTG datasheet |
|---|
| Product Photos | SOT 363 |
|---|
| Product Training Modules | TVS Diode Arrays - ESD Suppressors for I/O Interfaces |
|---|
| Catalog Drawings | SP0505,SP1001-05 Series Circuit |
|---|
| Standard Package | 3,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | SP05, SPA? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 5 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
|---|
| Voltage - Breakdown (Min) | - |
|---|
| Voltage - Clamping (Max) @ Ipp | 8.5V |
|---|
| Current - Peak Pulse (10/1000μs) | - |
|---|
| Power - Peak Pulse | - |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -40°C ~ 85°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
|---|
| Supplier Device Package | SC-70-6 |
|---|
| Online Catalog | SPA? SP0505 Series |
|---|
| Other Names | F3160TR SP0505BAJTG-ND |
|---|
We can supply Littelfuse Inc. part# SP0505BAJTG. Use the request quote form to request SP0505BAJTG pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SP0505BAJTG. The price and lead time for SP0505BAJTG depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SP0505BAJTG. We look forward to doing business with you.
