Technical Specifications of MAPLAD15KP70CAE3
| Datasheet |  MAPLAD15KP70CAE3 datasheet |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | Military, MIL-PRF-19500 |
|---|
| Packaging | Bulk |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 1 |
|---|
| Voltage - Reverse Standoff (Typ) | 70V |
|---|
| Voltage - Breakdown (Min) | 77.8V |
|---|
| Voltage - Clamping (Max) @ Ipp | 113V |
|---|
| Current - Peak Pulse (10/1000μs) | 132A |
|---|
| Power - Peak Pulse | 15000W (15kW) |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard SMD |
|---|
| Supplier Device Package | PLAD |
|---|
| Other Names | 1086-4775 |
|---|
We can supply Microsemi HI-REL [MIL] part# MAPLAD15KP70CAE3. Use the request quote form to request MAPLAD15KP70CAE3 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MAPLAD15KP70CAE3. The price and lead time for MAPLAD15KP70CAE3 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MAPLAD15KP70CAE3. We look forward to doing business with you.
