Technical Specifications of TPD1E05U06DPYR
| Datasheet |  TPD1E05U06DPYR datasheet |
|---|
| Product Photos | X2SON |
|---|
| Product Training Modules | ESD Protection Basics |
|---|
| PCN Assembly/Origin | Qualification Assembly/Test Site 16/Oct/2014 |
|---|
| Manufacturer Product Page | TPD1E05U06DPYR Specifications |
|---|
| Standard Package | 10,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Steering (Rail to Rail) |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 1 |
|---|
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
|---|
| Voltage - Breakdown (Min) | 6V |
|---|
| Voltage - Clamping (Max) @ Ipp | 14V |
|---|
| Current - Peak Pulse (10/1000μs) | 2.5A (8/20μs) |
|---|
| Power - Peak Pulse | 40W |
|---|
| Power Line Protection | Yes |
|---|
| Applications | HDMI |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -40°C ~ 125°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2-XDFN |
|---|
| Supplier Device Package | 2-X1SON (1x.60) |
|---|
| Online Catalog | TPD1E Series |
|---|
| Other Names | 296-39341-2 TPD1E05U06DPYR-ND |
|---|
We can supply Texas Instruments part# TPD1E05U06DPYR. Use the request quote form to request TPD1E05U06DPYR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TPD1E05U06DPYR. The price and lead time for TPD1E05U06DPYR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TPD1E05U06DPYR. We look forward to doing business with you.
