PCN13-96S-2.54DSA(71)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | PCN13-96S-2.54DSA(71) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | CONN DIN RCPT 96POS 3ROW STR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| PCN13-96S-2.54DSA(71) Price |  |
Technical Specifications of PCN13-96S-2.54DSA(71)
| Datasheet |  PCN13-96S-2.54DSA(71) datasheet |
|---|---|
| Product Photos | PCN13-96S-2.54DSA(71) |
| Catalog Drawings | 3 Row Socket Straight Top3 Row Socket Straight Foot Print |
| Standard Package | 15 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - DIN 41612 |
| Series | PCN13 |
| Packaging | Tray |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 96 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 3 |
| Style | C |
| Level, Class | 1 |
| Mounting Type | Through Hole |
| Termination | Solder |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | - |
| Operating Temperature | -55°C ~ 85°C |
| Current Rating | 2A |
| Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Online Catalog | PCN10 and PCN13 Series |
| Mating Products | H11215-ND - CONN DIN HEADER 96POS 3ROW R/A H11218-ND - CONN DIN HEADER 96POS 3ROW STR H11216-ND - CONN DIN HEADER 96POS 3ROW R/A H5096-ND - DIN CONN HEADER 96POS 3 ROW R/A H6096-ND - DIN CONN HEADER 96POS 3 ROW STR H5196-ND - DIN CONN HEADER 96POS 3ROW R/A |
| Other Names | *PCN13-96S-2.54DSA(71) H11223 PCN1396S254DSA71 |
