Technical Specifications of 120786-1
| Datasheet |  120786-1 datasheet |
|---|
| Product Photos | 120786-1 |
|---|
| RoHS Information | 120786-1 Statement of ComplianceRoHS 2 Statement |
|---|
| 3D Model | 120786-1.pdf |
|---|
| PCN Obsolescence/ EOL | 120yyy-1 05/Sep/2014 |
|---|
| Standard Package | 630 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Backplane Connectors - Specialized |
|---|
| Series | Z-PACK HS3 |
|---|
| Packaging | Tube |
|---|
| Connector Usage | Backplane |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Connector Style | Dual Beam, Center |
|---|
| Number of Positions | 60 |
|---|
| Number of Positions Loaded | All |
|---|
| Pitch | 0.098" (2.50mm) |
|---|
| Number of Rows | 6 |
|---|
| Number of Columns | 10 |
|---|
| Mounting Type | Through Hole, Right Angle |
|---|
| Termination | Press-Fit |
|---|
| Contact Layout, Typical | - |
|---|
| Features | - |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | Flash |
|---|
| Color | - |
|---|
| Current Rating | 1.15A |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Operating Temperature | -65°C ~ 105°C |
|---|
| Voltage Rating | 250V |
|---|
| Mating Products | A101804-ND - CONN HEADER 60POS 6ROW STR GOLD 5120737-1-ND - HS3 B/P HDR ASY 6R 60 P LEV 1 5120758-1-ND - Z-PACK HEADER ASSY 60P 5120674-2-ND - CONN HEADER 60POS 6ROW STR GOLD 120674-1-ND - CONN 2MM HM PLUG 60POS STR GOLD 120674-2-ND - Z-PACK HS3 HDR ASSY 60P 5120841-1-ND - Z-PACK HS3 HDR ASSY 60P 120679-1-ND - Z-PACK HS3 HDR ASSY 6R 60P FT 120679-2-ND - Z-PACK HS3 HDR ASSY 6R 60P FT 120771-1-ND - Z-PACK HS3 HDR ASSY 60P FT SEQ |
|---|
| Tooling | 1338742-1-ND - TOOL SEAT 6ROW HS3 Z-PACK 60POS |
|---|
| Other Names | 1207861 |
|---|
