MP2-H240-51P1-S-LR
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MP2-H240-51P1-S-LR |
|---|---|
| Manufacturer | 3M |
| Description | CONN HEADER 2-FB 240POS 5ROW |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MP2-H240-51P1-S-LR Price |  |
Technical Specifications of MP2-H240-51P1-S-LR
| Datasheet |  MP2-H240-51P1-S-LR datasheet |
|---|---|
| Standard Package | 100 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Specialized |
| Series | MetPak? MP2 |
| Packaging | Bulk |
| Connector Usage | Backplane |
| Connector Type | Header, Male Pins |
| Connector Style | Futurebus+? |
| Number of Positions | 240 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 5 |
| Number of Columns | - |
| Mounting Type | Through Hole |
| Termination | Press-Fit |
| Contact Layout, Typical | - |
| Features | Board Guide |
| Contact Finish | Gold |
| Contact Finish Thickness | 3μin (0.08μm) |
| Color | Beige |
| Current Rating | 1.5A |
| Material Flammability Rating | UL94 V-0 |
| Operating Temperature | -55°C ~ 125°C |
| Voltage Rating | - |
| Mating Products | MP2-S240-51S1-C-TG30-ND - CONN SOCKET INVERSE 240POS 5ROW MP2-SS240-51S1-TG30-ND - CONN SOCKET 2-FB 240POS 5ROW |
| Other Names | 00051111959794 70010023870 |
