307-010-521-101
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 307-010-521-101 |
|---|---|
| Manufacturer | EDAC Inc. |
| Description | CARDEDGE LO PRO 10POS .156 GRN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 307-010-521-101 Price |  |
Technical Specifications of 307-010-521-101
| Datasheet |  307-010-521-101 datasheet |
|---|---|
| Standard Package | 25 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | 307 |
| Packaging | Bulk |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 10 |
| Number of Positions | 20 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.156" (3.96mm) |
| Features | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Material | Copper, Nickel, Tin Alloy |
| Contact Finish | Gold |
| Contact Finish Thickness | - |
| Contact Type | - |
| Color | Green |
| Flange Feature | - |
| Operating Temperature | -65°C ~ 125°C |
| Material - Insulation | Polyester Thermoplastic |
| Read Out | Single |
