RCB92DHAS-S250
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | RCB92DHAS-S250 |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | EDGECARD PCI 184POS .050 R/A 5V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| RCB92DHAS-S250 Price |  |
Technical Specifications of RCB92DHAS-S250
| EDA / CAD Models | Download from Accelerated Designs |
|---|---|
| Standard Package | 1 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | - |
| Packaging | Tube |
| Card Type | PCI 5V 64 Bit |
| Gender | Female |
| Number of Positions/Bay/Row | 49; 11; 32 |
| Number of Positions | 184 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.050" (1.27mm) |
| Features | - |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder, Staggered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Contact Type | Hairpin Bellows |
| Color | Black |
| Flange Feature | Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia |
| Operating Temperature | -65°C ~ 125°C |
| Material - Insulation | Polyphenylene Sulfide (PPS) |
| Read Out | Dual |
