Technical Specifications of CA3100R20A48PXBF80
| Datasheet |  CA3100R20A48PXBF80 datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-5015, CA-B |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 20-A48 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Reverse Bayonet Lock |
|---|
| Orientation | X |
|---|
| Ingress Protection | IP67 - Dust Tight, Waterproof |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | - |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 22A |
|---|
| Voltage - Rated | 50V |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | CA3106E20A48SXB03-ND - CONN PLUG 19POS INLINE W/SKTS CA3106E20A48SXB01-ND - CONN PLUG 19POS INLINE W/SKTS CA3106E20A48SXB02-ND - CONN PLUG 19POS INLINE W/SKTS CA3106E20A48SXBF80-ND - CONN PLUG 19POS INLINE W/SKTS CA3106F20A48SXBF80-ND - CONN PLUG 19POS INLINE W/SKTS |
|---|
We can supply ITT Cannon, LLC part# CA3100R20A48PXBF80. Use the request quote form to request CA3100R20A48PXBF80 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CA3100R20A48PXBF80. The price and lead time for CA3100R20A48PXBF80 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CA3100R20A48PXBF80. We look forward to doing business with you.
