Technical Specifications of KPSE0E14-19SDN
| Datasheet |  KPSE0E14-19SDN datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 14-19 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE06F14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS 1003-1121-ND - CONN PLUG 19POS INLINE W/PIN IKPSE06E14-19PF0-ND - CONN HSG INLINE MNT PLUG 19POS IKPSE06E14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE06F14-19PF0-ND - CONN HSG INLINE MNT PLUG 19POS IKPSE6F14-19PDX-ND - CONN PLUG 19POS W/PIN IKPSE06F14-19PDX-ND - CONN PLUG 19POS W/PIN INLINE KPSE06P14-19P-ND - CONN PLUG 19POS INLINE PIN IKPSE06E14-19PDNF0-ND - CONN HSG INLINE MNT PLUG 19POS IKPSE6E14-19PF185-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE6E14-19PDN-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE06E14-19PDN-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE06F14-19PDN-ND - CONN PLUG 19POS INLINE W/PIN IKPSE08F14-19PF0-ND - CONN HSG R/A INLINE PLUG 19POS IKPSE08E14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE08F14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS IKPT06E14-19PDN-ND - CONN PLUG 19POS W/PIN INLINE IKPT06E14-19P-ND - CONN PLUG 19POS INLINE W/PIN IKPTR6E14-19P-ND - CONN PLUG 19POS W/PIN INLINE IKPT08E14-19P-ND - CONN PLUG 19POS W/PIN INLINE R/A IKPT08F14-19P-ND - CONN PLUG 19POS W/PIN INLINE R/A IKPT06J14-19P-ND - CONN PLUG 19POS INLINE W/PIN IKPSE06J14-19PF0-ND - CONN HSG INLINE MNT PLUG 19POS IKPSE06J14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS KPSE08P14-19P-ND - CONN PLUG 19POS INLINE RA PIN |
|---|
| Other Names | IKPSE0E14-19SDN KPSE0E1419SDN |
|---|
We can supply ITT Cannon, LLC part# KPSE0E14-19SDN. Use the request quote form to request KPSE0E14-19SDN pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE0E14-19SDN. The price and lead time for KPSE0E14-19SDN depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE0E14-19SDN. We look forward to doing business with you.
