Technical Specifications of MS3126F12-10PW
| Datasheet |  MS3126F12-10PW datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 10 |
|---|
| Shell Size - Insert | 12-10 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | W |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IMS3122E12-10SW-ND - CONN RCPT 10POS BOX MNT W/SCKT IMS3121P12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKT IMS3124P12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKT IMS3121E12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKT IMS3124E12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKT IMS3124F12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKT IMS3112E12-10SW-ND - CONN RCPT 10POS BOX MNT W/SCKT IMS3111F12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKT IMS3114E12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKT IMS3121F12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKT IMS3114P12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKT IMS3114F12-10SW-ND - CONN RCPT 10POS JAM NUT W/SCKT IMS3111J12-10SW-ND - CONN RCPT 10POS CBL MNT W/SCKT |
|---|
| Other Names | IMS3126F12-10PW MS3126F12-10PWPEI MS3126F12-10PWPEI-ND MS3126F1210PW |
|---|
We can supply ITT Cannon, LLC part# MS3126F12-10PW. Use the request quote form to request MS3126F12-10PW pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MS3126F12-10PW. The price and lead time for MS3126F12-10PW depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MS3126F12-10PW. We look forward to doing business with you.
