Technical Specifications of KPSE06F16-26PW
| Datasheet |  KPSE06F16-26PW datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 26 |
|---|
| Shell Size - Insert | 16-26 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | W |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE02E16-26SWF0-ND - CONN HSG BOX MNT RCPT 26POS IKPT02E16-26SWEW-ND - CONN RCPT 26POS W/SKT BOX IKPSE02E16-26SW-ND - CONN RCPT 26POS BOX MNT W/SKTS KPSE00F16-26SW-ND - CONN RCPT 26POS WALL MNT SKT IKPSE01F16-26SW-ND - CONN RCPT 26POS CBL MNT W/SKTS IKPSE07E16-26SW-ND - CONN RCPT 26POS JAM NUT W/SKTS IKPSE07F16-26SW-ND - CONN RCPT 26POS JAM NUT W/SKTS IKPSE01J16-26SW-ND - CONN RCPT 26POS CBL MNT W/SKTS IKPT02E16-26SW-ND - CONN RCPT 26POS W/SKT BOX IKPT01J16-26SW-ND - CONN RCPT 26POS W/SKT INLINE KPT07P16-26SW-ND - CONN RCPT 26POS JAM NUT SKT IKPT01F16-26SW-ND - CONN RCPT 26POS W/SKT INLINE IKPSE01E16-26SW-ND - CONN RCPT 26POS CBL MNT W/SKTS IKPT07E16-26SW-ND - CONN RCPT 26POS W/SKT JAM NUT KPSE00E16-26SW-ND - CONN RCPT 26POS WALL MNT SKT KPSE7E16-26SWDN-ND - CONN RCPT 26POS JAM NUT SKT KPT00E16-26SW-ND - CONN RCPT 26POS WALL MNT SKT |
|---|
| Other Names | IKPSE06F16-26PW KPSE06F1626PW |
|---|
We can supply ITT Cannon, LLC part# KPSE06F16-26PW. Use the request quote form to request KPSE06F16-26PW pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE06F16-26PW. The price and lead time for KPSE06F16-26PW depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE06F16-26PW. We look forward to doing business with you.
