Technical Specifications of KPSE08B14-19S
| Datasheet |  KPSE08B14-19S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 14-19 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line), Right Angle |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | - |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE01D14-19P-ND - CONN RCPT 19POS CBL MNT W/PINS KPT02A14-19P-ND - CONN RCPT 19POS BOX MNT PIN IKPT07A14-19PF0-ND - CONN HSG JAM NUT RCPT 19POS IKPT07A14-19PEW-ND - CONN RCPT 19POS W/PIN JAM NUT IKPT7A14-19PEW-ND - CONN RCPT 19POS W/PIN JAM NUT IKPT07A14-19P-ND - CONN RCPT 19POS W/PIN JAM NUT IKPT7A14-19PEX-ND - CONN RCPT 19POS W/PIN JAM NUT IKPT00A14-19P-ND - CONN RCPT 19POS WALL W/PIN IKPT01A14-19P-ND - CONN RCPT 19POS W/PIN INLINE IKPT07A14-19PDV-ND - CONN RCPT 19POS W/PIN JAM NUT KPT07B14-19P-ND - CONN RCPT 19POS JAM NUT PIN PV72W14-19P-ND - CONN RCPT 19POS WALL MNT W/PINS PV74W14-19P-ND - CONN RCPT 19POS JAM NUT W/PINS IKPSE07A14-19PF0-ND - CONN HSG JAM NUT RCPT 19POS IKPT00B14-19P-ND - CONN RCPT 19POS W/PIN WALL IKPT01B14-19P-ND - CONN RCPT 19POS W/PIN INLINE IKPSE07A14-19P-ND - CONN RCPT 19POS JAM NUT W/PINS IKPSE00A14-19P-ND - CONN RCPT 19POS WALL MNT W/PINS IKPSE01A14-19P-ND - CONN RCPT 19POS CBL MNT W/PINS IKPSE01B14-19P-ND - CONN RCPT 19POS CBL MNT W/PINS KPSE02A14-19P-ND - CONN RCPT 19POS BOX MNT PIN KPSE02A14-19PF0-ND - CONN HSG RCPT BOX MNT 19POS PIN KPSE07B14-19P-ND - CONN RCPT 19POS JAM NUT PIN |
|---|
| Other Names | IKPSE08B14-19S KPSE08B1419S |
|---|
We can supply ITT Cannon, LLC part# KPSE08B14-19S. Use the request quote form to request KPSE08B14-19S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE08B14-19S. The price and lead time for KPSE08B14-19S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE08B14-19S. We look forward to doing business with you.
