Technical Specifications of KPSE01F22-55PW
| Datasheet |  KPSE01F22-55PW datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 55 |
|---|
| Shell Size - Insert | 22-55 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | W |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE06E22-55SW-ND - CONN PLUG 55POS CBL MNT W/SKTS IKPSE6E22-55SWDN-ND - CONN PLUG 55POS CBL MNT W/SKTS IKPSE06E22-55SWDN-ND - CONN PLUG 55POS CBL MNT W/SKTS IKPT06E22-55SW-ND - CONN PLUG 55POS INLINE W/SKT IKPT06F22-55SW-ND - CONN PLUG 55POS INLINE W/SKT IKPSE06F22-55SW-ND - CONN PLUG 55POS CBL MNT W/SKTS IKPSE6F22-55SWDX-ND - CONN PLUG 55POS W/SKT IKPT08F22-55SW-ND - CONN PLUG 55POS INLINE W/SKT R/A IKPSE08F22-55SW-ND - CONN PLUG 55POS CBL MNT W/SKTS IPV76W22-55SW-ND - CONN PLUG 55POS STRAIGHT W/SKTS |
|---|
| Other Names | IKPSE01F22-55PW KPSE01F2255PW |
|---|
We can supply ITT Cannon, LLC part# KPSE01F22-55PW. Use the request quote form to request KPSE01F22-55PW pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE01F22-55PW. The price and lead time for KPSE01F22-55PW depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE01F22-55PW. We look forward to doing business with you.
