Technical Specifications of KPT06E16-26SDZ
| Datasheet |  KPT06E16-26SDZ datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 26 |
|---|
| Shell Size - Insert | 16-26 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shielded, Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | KPSE0E16-26PDZ-ND - CONN RCPT 26POS WALL MNT PIN IKPSE1E16-26PDZ-ND - CONN RCPT 26POS CBL MNT W/PINS IKPSE01E16-26PDZ-ND - CONN RCPT 26POS CBL MNT W/PINS KPT00E16-26PDZ-ND - CONN RCPT 26POS WALL MNT PIN |
|---|
| Other Names | IKPT06E16-26SDZ KPT06E1626SDZ |
|---|
We can supply ITT Cannon, LLC part# KPT06E16-26SDZ. Use the request quote form to request KPT06E16-26SDZ pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPT06E16-26SDZ. The price and lead time for KPT06E16-26SDZ depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPT06E16-26SDZ. We look forward to doing business with you.
