Technical Specifications of KPSE00B14-15S
| Datasheet |  KPSE00B14-15S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 15 |
|---|
| Shell Size - Insert | 14-15 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | - |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A, 13A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | KPSE08B14-15P-ND - CONN PLUG 15POS INLINE RA PIN IKPT06A14-15P-ND - CONN PLUG 15POS INLINE W/PIN IKPSE06A14-15P-ND - CONN PLUG 15POS CBL MNT W/PINS IKPT08A14-15P-ND - CONN PLUG 15POS W/PIN INLINE R/A IKPT08B14-15P-ND - CONN PLUG 15POS W/PIN INLINE R/A KPSE08A14-15P-ND - CONN PLUG 15POS INLINE RA PIN IKPT06B14-15P-ND - CONN PLUG 15POS W/PIN INLINE PV76W14-15P-ND - CONN PLUG 15POS STRAIGHT W/PINS KPSE06B14-15P-ND - CONN PLUG 15POS INLINE PIN |
|---|
| Other Names | IKPSE00B14-15S KPSE00B1415S |
|---|
We can supply ITT Cannon, LLC part# KPSE00B14-15S. Use the request quote form to request KPSE00B14-15S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE00B14-15S. The price and lead time for KPSE00B14-15S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE00B14-15S. We look forward to doing business with you.
