Technical Specifications of MS3100F22-14P
| Datasheet |  MS3100F22-14P datasheet |
|---|
| Product Training Modules | Mil-DTL-5015 and AC Threaded Connectors |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-5015 |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 22-14 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Threaded |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | - |
|---|
| Voltage - Rated | 500VAC, 700VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | AMS3106R22-14S-ND - CONN PLUG 19POS STRAIGHT W/SCKT AMS3106F22-14S-ND - CONN PLUG 19POS STRAIGHT W/SCKT |
|---|
| Associated Product | 1591-1031-MIL - RCPT COVER SHELL SIZE 22 CADMIUM |
|---|
| Other Names | MS3100F22-14P-ND |
|---|
We can supply Amphenol Industrial Operations part# MS3100F22-14P. Use the request quote form to request MS3100F22-14P pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MS3100F22-14P. The price and lead time for MS3100F22-14P depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MS3100F22-14P. We look forward to doing business with you.
