Technical Specifications of KPSE08P22-55P
| Datasheet |  KPSE08P22-55P datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 55 |
|---|
| Shell Size - Insert | 22-55 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line), Right Angle |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Potted |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE02E22-55SF0-ND - CONN HSG BOX MNT RCPT 55POS IKPT2E22-55SEW-ND - CONN RCPT 55POS W/SKT BOX IKPT2E22-55SEX-ND - CONN RCPT 55POS W/SKT BOX IKPSE02E22-55S-ND - CONN RCPT 55POS BOX MNT W/SKTS IKPSE00E22-55S-ND - CONN RCPT 55POS WALL MNT W/SKTS IKPSE01E22-55S-ND - CONN RCPT 55POS CBL MNT W/SKTS IKPSE00E22-55SDX-ND - CONN RCPT 55POS WALL MNT W/SKTS IKPSE0E22-55SDX-ND - CONN RCPT 55POS WALL MNT W/SKTS IKPSE0E22-55SDN-ND - CONN RCPT 55POS WALL MNT W/SKTS IKPSE01E22-55SDN-ND - CONN RCPT 55POS CBL MNT W/SKTS IKPSE07E22-55S-ND - CONN RCPT 55POS JAM NUT W/SKTS KPSE00P22-55S-ND - CONN RCPT 55POS WALL MNT SKT IKPT07E22-55SEX-ND - CONN RCPT 55POS W/SKT JAM NUT KPSE07E22-55SDX-ND - CONN RCPT 55POS JAM NUT SKT IMS3111J22-55S-ND - CONN RCPT 55POS CBL MNT W/SCKT IKPSE07F22-55S-ND - CONN RCPT 55POS JAM NUT W/SKTS IKPT00E22-55SDN-ND - CONN RCPT 55POS W/SKT WALL IKPT02E22-55S-ND - CONN RCPT 55POS W/SKT BOX IMS3110J22-55S-ND - CONN RCPT 55POS WALL MNT W/SCKT IKPT00J22-55S-ND - CONN RCPT 55POS WALL W/SKT IKPT01J22-55S-ND - CONN RCPT 55POS W/SKT INLINE IKPSE00J22-55S-ND - CONN RCPT 55POS WALL MNT W/SKTS IKPSE01J22-55S-ND - CONN RCPT 55POS CBL MNT W/SKTS IKPT00E22-55S-ND - CONN RCPT 55POS WALL W/SKT IKPT01E22-55S-ND - CONN RCPT 55POS W/SKT INLINE IKPT07E22-55S-ND - CONN RCPT 55POS JAM NUT W/SKT IKPT00P22-55S-ND - CONN RCPT 55POS W/SKT WALL IKPSE01F22-55SF0-ND - CONN HSG INLINE MNT RCPT 55POS IKPT00F22-55S-ND - CONN RCPT 55POS WALL W/SKT IKPT01F22-55S-ND - CONN RCPT 55POS W/SKT INLINE IKPSE00F22-55S-ND - CONN RCPT 55POS WALL MNT W/SKTS IKPSE01F22-55S-ND - CONN RCPT 55POS CBL MNT W/SKTS IKPT07F22-55S-ND - CONN RCPT 55POS W/SKT JAM NUT KPSE1E22-55SDN-ND - CONN RCPT 55POS CBL MNT SKT KPT0E22-55SDN-ND - CONN RCPT 55POS WALL MNT SKT |
|---|
| Other Names | IKPSE08P22-55P KPSE08P2255P |
|---|
We can supply ITT Cannon, LLC part# KPSE08P22-55P. Use the request quote form to request KPSE08P22-55P pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE08P22-55P. The price and lead time for KPSE08P22-55P depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE08P22-55P. We look forward to doing business with you.
