Technical Specifications of KPSE0E168P-DZ
| Datasheet |  KPSE0E168P-DZ datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 8 |
|---|
| Shell Size - Insert | 16-8 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shielded, Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 13A |
|---|
| Voltage - Rated | 1000VAC, 1400VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT06F16-8S23-ND - CONN PLUG 8POS W/SKT INLINE IKPT06E16-8SDZ-ND - CONN PLUG 8POS W/SKT INLINE IKPSE06E16-8SDZ-ND - CONN PLUG 8POS CBL MNT W/SKTS IKPSE6E16-8SDZ-ND - CONN PLUG 8POS CBL MNT W/SKTS KPT6E16-8SDZ-ND - CONN PLUG 8POS INLINE SKT |
|---|
| Other Names | KPSE0E168PDZ |
|---|
We can supply ITT Cannon, LLC part# KPSE0E168P-DZ. Use the request quote form to request KPSE0E168P-DZ pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE0E168P-DZ. The price and lead time for KPSE0E168P-DZ depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE0E168P-DZ. We look forward to doing business with you.
