Technical Specifications of AYF334535A
| Datasheet |  AYF334535A datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
|---|
| Manufacturer | Panasonic-Electric-Works |
|---|
| Series | Y3B |
|---|
| Packaging | Strip |
|---|
| Flat Flex Type | FPC |
|---|
| Mounting Type | Surface Mount, Right Angle |
|---|
| Connector/Contact Type | Contacts, Top and Bottom |
|---|
| Number of Positions | 45 |
|---|
| Pitch | 0.012" (0.30mm) |
|---|
| Termination | Solder |
|---|
| FFC, FCB Thickness | 0.20mm |
|---|
| Height Above Board | 0.036" (0.90mm) |
|---|
| Locking Feature | Flip Lock, Backlock |
|---|
| Cable End Type | Tapered |
|---|
| Contact Material | Copper Alloy |
|---|
| Contact Finish | Gold |
|---|
| Housing Material | Liquid Crystal Polymer (LCP) |
|---|
| Actuator Material | Liquid Crystal Polymer (LCP) |
|---|
| Features | - |
|---|
| Voltage Rating | 50V |
|---|
| Operating Temperature | -55°C ~ 85°C |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | 0.2A per Contact |
|---|
We can supply Panasonic Electric Works part# AYF334535A. Use the request quote form to request AYF334535A pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AYF334535A. The price and lead time for AYF334535A depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# AYF334535A. We look forward to doing business with you.
