04FMN-BMTTR-A-TB(LF)(SN)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 04FMN-BMTTR-A-TB(LF)(SN) |
|---|---|
| Manufacturer | JST Sales America Inc. |
| Description | 4 Position FFC Connector Contacts, Vertical, 1 Sided 0.039" (1.00mm) Surface Mount |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 04FMN-BMTTR-A-TB(LF)(SN) Price |  |
Technical Specifications of 04FMN-BMTTR-A-TB(LF)(SN)
| Datasheet |  04FMN-BMTTR-A-TB(LF)(SN) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | FFC, FPC (Flat Flexible) Connectors |
| Manufacturer | JST-Sales-America-Inc. |
| Series | FMN |
| Packaging | Tape & Reel (TR) |
| Flat Flex Type | FFC |
| Mounting Type | Surface Mount |
| Connector/Contact Type | Contacts, Vertical, 1 Sided |
| Number of Positions | 4 |
| Pitch | 0.039" (1.00mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.201" (5.10mm) |
| Locking Feature | - |
| Cable End Type | Straight |
| Contact Material | Phosphor Bronze |
| Contact Finish | Tin |
| Housing Material | Polyamide (PA6T), Nylon 6T |
| Actuator Material | - |
| Features | Low Insertion Force (LIF) |
| Voltage Rating | 50V |
| Operating Temperature | -25°C ~ 85°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating | 0.5A |
