FH16-60S-0.3SHW(05)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FH16-60S-0.3SHW(05) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | 60 Position FPC Connector Contacts, Bottom 0.012" (0.30mm) Surface Mount, Right Angle |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FH16-60S-0.3SHW(05) Price |  |
Technical Specifications of FH16-60S-0.3SHW(05)
| Category | Connectors, Interconnects |
|---|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
| Manufacturer | Hirose-Electric-Co-Ltd |
| Series | FH16 |
| Packaging | Tape & Reel (TR) |
| Flat Flex Type | FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Bottom |
| Number of Positions | 60 |
| Pitch | 0.012" (0.30mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.118" (3.00mm) |
| Locking Feature | Flip Lock |
| Cable End Type | Tabbed |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Housing Material | Liquid Crystal Polymer (LCP), Polyamide (PA), Nylon |
| Actuator Material | Polyphenylene Sulfide (PPS) |
| Features | Pick and Place Cap, Zero Insertion Force (ZIF) |
| Voltage Rating | 30V |
| Operating Temperature | -40°C ~ 70°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating | 0.15A |
