RJMG233022610ER
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | RJMG233022610ER |
|---|---|
| Manufacturer | Amphenol Commercial Products |
| Description | 1 Port RJ45 with USB A Magjack Connector Through Hole 10/100/1000 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| RJMG233022610ER Price |  |
Technical Specifications of RJMG233022610ER
| Datasheet |  RJMG233022610ER datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Amphenol-Commercial-Products |
| Series | RJMG |
| Packaging | Tray |
| Connector Type | RJ45 with USB A |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.830" (21.08mm) |
| LED Color | Green, Orange - Yellow |
| Number of Cores per Jack | 12 |
| Shielding | Shielded, EMI Finger |
| Features | Board Lock |
| Tab Direction | Up |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Shield Material | Stainless Steel |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Operating Temperature | 0°C ~ 70°C |
