ARJ11F-MASD-AB-A-FM2
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ARJ11F-MASD-AB-A-FM2 |
|---|---|
| Manufacturer | Abracon LLC |
| Description | 1 Port RJ45 Magjack Connector Through Hole 10/100/1000 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ARJ11F-MASD-AB-A-FM2 Price |  |
Technical Specifications of ARJ11F-MASD-AB-A-FM2
| Datasheet |  ARJ11F-MASD-AB-A-FM2 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Abracon-LLC |
| Series | ARJ11F |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.531" (13.50mm) |
| LED Color | Green, Yellow - Green |
| Number of Cores per Jack | 8 |
| Shielding | Shielded, EMI Finger |
| Features | Board Lock |
| Tab Direction | Up |
| Contact Material | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 6μin (0.152μm) |
| Shield Material | - |
| Housing Material | - |
| Operating Temperature | 0°C ~ 70°C |
