0857271012
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0857271012 |
|---|---|
| Manufacturer | Molex, LLC |
| Description | 8 Port RJ45 Magjack Connector Through Hole 10/100/1000 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 0857271012 Price |  |
Technical Specifications of 0857271012
| Datasheet |  0857271012 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Molex,-LLC |
| Series | 85727 |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 8 |
| Number of Rows | 2 |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 1.002" (25.46mm) |
| LED Color | Yellow, Green - Yellow, Green |
| Number of Cores per Jack | 8 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide |
| Tab Direction | Up and Down |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Shield Material | Brass |
| Housing Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
| Operating Temperature | 0°C ~ 70°C |
