MDF7S-30DP-2.54DSA(55)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MDF7S-30DP-2.54DSA(55) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | CONN HDR 30POS 2.54MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MDF7S-30DP-2.54DSA(55) Price |  |
Technical Specifications of MDF7S-30DP-2.54DSA(55)
| Datasheet |  MDF7S-30DP-2.54DSA(55) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Hirose-Electric-Co-Ltd |
| Series | MDF7 |
| Packaging | Bulk |
| Number of Positions | 30 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Length - Overall | 1.063" (27.00mm) |
| Length - Post (Mating) | 0.118" (3.00mm) |
| Length - Stack Height | 0.845" (21.46mm) |
| Length - Tail | 0.118" (3.00mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish - Post (Mating) | Tin |
| Contact Finish Thickness - Post (Mating) | 39μin (1.00μm) |
| Color | Black, Gray |
