6-102567-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 6-102567-1 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CONN HEADER VERT .100 20POS 15AU |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 6-102567-1 Price |  |
Technical Specifications of 6-102567-1
| Datasheet |  6-102567-1 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Male Pins |
| Manufacturer | TE-Connectivity-AMP-Connectors |
| Series | AMPMODU Mod II |
| Packaging | Tube |
| Connector Type | Shrouded |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Height Stacking (Mating) | - |
| Molding Height Above Board | 0.550" (13.97mm) |
| Contact Mating Length | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish | Gold |
| Contact Finish Thickness | 15μin (0.38μm) |
| Features | - |
| Color | Black |
