M50-4901345
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | M50-4901345 |
|---|---|
| Manufacturer | Harwin Inc. |
| Description | CONN HDR 1.27MM SMD AU 26POS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| M50-4901345 Price |  |
Technical Specifications of M50-4901345
| Datasheet |  M50-4901345 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Male Pins |
| Manufacturer | Harwin-Inc. |
| Series | Archer M50 |
| Packaging | Tube |
| Connector Type | Shrouded |
| Number of Positions | 26 |
| Number of Positions Loaded | All |
| Pitch | 0.050" (1.27mm) |
| Number of Rows | 2 |
| Row Spacing | 0.050" (1.27mm) |
| Height Stacking (Mating) | 0.272" (6.90mm) |
| Molding Height Above Board | 0.224" (5.70mm) |
| Contact Mating Length | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Finish | Gold |
| Contact Finish Thickness | - |
| Features | - |
| Color | Black |
