7820-0006PR
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 7820-0006PR |
|---|---|
| Manufacturer | 3M |
| Description | 20 Position Ribbon Cable, DIP Header Connector Gray IDC 26 AWG, Stranded; 28 AWG, Solid or Stranded; 30 AWG, Solid Through Hole |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 7820-0006PR Price |  |
Technical Specifications of 7820-0006PR
| Datasheet |  7820-0006PR datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Board In, Direct Wire to Board |
| Manufacturer | 3M |
| Series | 78XX |
| Packaging | Tray |
| Connector Type | Ribbon Cable, DIP Header |
| Number of Positions | 20 |
| Cable Pitch | 0.050" (1.27mm) |
| Board-Side Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Cable Termination | IDC |
| Wire Gauge | 26 AWG, Stranded; 28 AWG, Solid or Stranded; 30 AWG, Solid |
| Features | Feed Through |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Color | Gray |
| Number of Positions Loaded | All |
