M80-4D12042S1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | M80-4D12042S1 |
|---|---|
| Manufacturer | Harwin Inc. |
| Description | CONN RECEPT 22AWG 20POS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| M80-4D12042S1 Price |  |
Technical Specifications of M80-4D12042S1
| Datasheet |  M80-4D12042S1 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Free Hanging, Panel Mount |
| Manufacturer | Harwin-Inc. |
| Series | Datamate J-Tek |
| Packaging | Bulk |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Number of Positions | 20 |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 2 |
| Row Spacing | 0.079" (2.00mm) |
| Mounting Type | Free Hanging (In-Line) |
| Fastening Type | - |
| Cable Termination | Crimp |
| Wire Type | Discrete |
| Wire Gauge | 22 AWG |
| Features | Jackscrews, Shielded |
| Contact Finish | Gold |
| Contact Finish Thickness | 12μin (0.30μm) |
| Color | Black |
