146135-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 146135-1 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 4 Positions Header, Unshrouded, Breakaway Connector 0.100" (2.54mm) Surface Mount Tin-Lead |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 146135-1 Price |  |
Technical Specifications of 146135-1
| Datasheet |  146135-1 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | TE Connectivity AMP Connectors |
| Series | AMPMODU Mod II |
| Packaging | Tube |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded, Breakaway |
| Number of Positions | 4 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Contact Mating Length | 0.320" (8.13mm) |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | - |
| Features | - |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 100μin (2.54μm) |
| Color | Black |
