DF7-7P-3.96DS(25)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DF7-7P-3.96DS(25) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | 7 Positions Header, Shrouded Connector 0.156" (3.96mm) Through Hole, Right Angle Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DF7-7P-3.96DS(25) Price |  |
Technical Specifications of DF7-7P-3.96DS(25)
| Category | Connectors, Interconnects |
|---|---|
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Hirose Electric Co Ltd |
| Series | DF7 |
| Packaging | Tray |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 7 |
| Number of Positions Loaded | All |
| Pitch | 0.156" (3.96mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.276" (7.00mm) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | Latch Holder |
| Features | Board Guide |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Beige |
