IL-7P-S3EN2-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | IL-7P-S3EN2-1 |
|---|---|
| Manufacturer | JAE Electronics |
| Description | 7 Positions Header, Unshrouded Connector 0.098" (2.50mm) Through Hole Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| IL-7P-S3EN2-1 Price |  |
Technical Specifications of IL-7P-S3EN2-1
| Datasheet |  IL-7P-S3EN2-1 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | JAE Electronics |
| Series | IL |
| Packaging | Bulk |
| Contact Type | Male Pin |
| Connector Type | Header, Unshrouded |
| Number of Positions | 7 |
| Number of Positions Loaded | All |
| Pitch | 0.098" (2.50mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | 0.236" (6.00mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Friction Lock |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 3.9μin (0.10μm) |
| Color | Brown |
